Details

Parameter name		LC-009OD (dual power supply for splicing wall)	LC-009OS (single power supply for mosaic wall)	LC-009SS (single power supply for TV)
Module composition	Pixel structure	Surface-mounted triple LED	Surface-mounted triple LED	Surface-mounted triple LED
	Pixel pitch（mm）	0.9375	0.9375	0.9375
	Module resolution (W × H)	128×180	128×180	128×180
	Module size (mm)	120（W）×168.75（H）×10（D）	120（W）×168.75（H）×10（D）	120（W）×168.75（H）×10（D）
	Module weight (Kg)	0.24	0.24	0.24
Unit composition	Unit module composition (W × H)	10×4	10×4	10×4
	Unit resolution (W × H)	1280×720	1280×720	1280×720
	Unit size (mm)	1200（W）×675（H）×99（D）	1200（W）×675（H）×99（D）	1200（W）×675（H）×99（D）
	Unit area (㎡)	0.81	0.81	0.81
	Conventional weight (kg / unit; kg / ㎡)	29.1；35.9	27.4；33.9	27.3；33.7
	Pixel density (pixel / ㎡)	1137777	1137777	1137777
	Box flatness (mm)	≤0.2	≤0.2	≤0.2
Optical parameters	Single point brightness correction	have	have	have
	Single point color correction	have	have	have
	White Balance Brightness (nits)	600 (color temperature 6500K, after correction)	600 (color temperature 6500K, after correction)	600 (color temperature 6500K, after correction)
	Color temperature (K)	3000—10000  Adjustable	3000—10000    Adjustable	3000—10000     Adjustable
	Horizontal viewing angle (°)	160	160	160
	Vertical viewing angle (°)	140	140	140
	The center of the light is deviated from the center	<3%	<3%	<3%
	Brightness uniformity	≥97%	≥97%	≥97%
	Chromaticity uniformity	± 0.003Cx, Cy within	± 0.003Cx, Cy within	± 0.003Cx, Cy within
	Contrast	5000:1	5000:1	5000:1
Electrical parameters	Peak power consumption (W / unit; W / ㎡)	360 ；450	360 ；450	360 ；450
	Average power consumption (W / unit; W / ㎡)	128；160	128；160	128；160
	Power supply requirements	AC100~240V（50-60Hz）	AC100~240V（50-60Hz）	AC100~240V（50-60Hz）
	Power supply configuration	Dual power supply	Single power supply	Single power supply
Processing performance	Drive mode	Constant Current Driver	Constant Current Driver	Constant Current Driver
	Change frame frequency (Hz)	50&60	50&60	50&60
	Refresh rate (Hz)	1920	1920	1920
